7-90 – 2026 CHEMGROUT CG550 GROUT PLANT (Air)

CG550
Condition New
Year 2026
Email Us Call Us

Details

Condition New
Category Grout-Plants-Silos
Make
Year 2026

Description

Boost grout productivity with the CG550 Air-Powered Grout Plant

Get rugged reliability and nonstop output in a compact, single-operator package. The ChemGrout CG550 pairs a high-efficiency 45-gallon (170 L) paddle mixer with a proven CG-030 piston pump, delivering continuous production and easy control from a central panel.

Why contractors choose the CG550 Air

  • Powerful, consistent output: Up to 16 gpm (60 lpm) at 400 psi for fast, even placement on demanding jobs.
  • True single-operator workflow: Mix, transfer, and pump simultaneously thanks to the large mix tank and holding hopper.
  • Handles tough materials: From fluid slurries to heavily sanded mixes—cement/sand, bentonites, non-shrink grouts, repair mortars, and more.
  • Air-powered simplicity: Requires 150 CFM at 100 PSI—no engine maintenance, no emissions at the point of use.
  • Built for uptime: Quick staple-lock construction and rapid U-clip disassembly let you access components fast. Pump breaks down with a hammer for thorough cleaning.
  • Smooth, continuous feed: Elevated hopper and slide gate move material cleanly, reducing blockages and keeping tremmie lines flowing.
  • Precise control: Variable-speed controls on both mixer and pump to match material and application.
  • Compact and tough: Skid-mounted footprint (approx. 64″ x 31″ x 56″), 490 lb—easy to position on site and built to take a beating.

Ideal applications

  • Soil nails, tiebacks, earth anchors
  • Cable and rock bolts, foundation stabilization
  • Pavement undersealing, slabjacking and slab raising
  • Underwater foundations, piers, deep well casing and sealing
  • Machine bases, abandonment, geothermal

Key specs (Air-powered CG550/030)

  • Max output/pressure: 16 gpm (60 lpm) at 400 psi
  • Power requirement: 150 CFM, 100 PSI
  • Configuration: Skid-mounted, single operator, 45-gallon mixer with large holding hopper
  • Materials: Most pre-packed non-shrink grouts, cement/sand, bentonite mixes, repair mortars, slurry products

7-90 CG550 030 Piston AIR PO498 SN17871 March 19 2026 Full Specs
